Applicable Standard
Design Standard: API 600, BS1414, DIN3352
Face to Face: ASME B16.10, EN 558, DIN3202
End Flange: ASME B16.5, ASME B16.47, DIN2533
Buttwelding Ends: ASME B16.25,
Inspection and Test: API 598,
Products Range
Size: 2" ~ 24"(DN50 ~ DN600)
Rating: ANSI 150LB
Body Materials: Bronze
Trim: bronze trim
Operation: Handwheel, Gear, Electric, Pneumatic, Hydraulic
Design Features
Full port design
OS&Y, outside and screw
Bolted bonnet, back seal structure
Flexible wedge, fully guided
Choice of Solid or split wedge
Renewable or welded seat
Extended stem design for low temperature
Flanged or butt-welding ends
|
